Place of Origin:
Chengdu, China
Brand Name:
ZEVAUTO
Certification:
ISO
Model Number:
CDL6100LRBEV
The electric coach series is specially designed for the intercity travel, business and tourism of medium and long distance. It is equipped with high-quality and high-strength skeleton body. It is very safe, environmental friendly and comfortable. Passengers can enjoy the journey anytime and anywhere. It is environmentally friendly, making every journey intimate and reassuring for every passenger.
| Overall specs | Passenger capacity | 45+1 seats | Motor specs | Manufacturer | ZEV |
| Vehicle size (mm) | 10990*2500*3600 | Model | ZEV | ||
| Wheel base (mm) | 5700 | Position | Rear | ||
| Front/Rear overhang | 2290/3000 | Motor type | PMSM | ||
| Front/Rear tread | 2060/1865 | Max.power(kw/rpm) | 160 | ||
| Approach/Departure(º) | 10/9 | Max. torque (N.m/rpm) | 1200 | ||
| Max. Grade-ability(%) | ≥20% | Displacement(L) | -- | ||
| Top speed (km/h) | 110km/h | Fuel | Electric | ||
| Curb weight (kg) | 11600 | Emission | -- | ||
| Gross weight (kg) | 17700 | ||||
| Battery | 238.06 kwh,LiFePo4 | ||||
| Cruising range | ≥200km | ||||
| Charging Time | Within 2 hours | ||||
| Item | Specs | Remarks | |||
| Chassis | Front axle | DANA | |||
| Rear axle | DANA | ||||
| Transmission | Auto transmission | ||||
| Suspension | Air bag | ||||
| Steering | Integral power steering | ||||
| Braking | Front disc and rear drum ; dual circuit air brake, WABCO ABS, slack adjuster | ||||
| Tyre | 11R22.5 steel rim Tubeless radial tire | ||||
| Battery | Maintenance-free type | ||||
| electronics | AC | 30000kcal/h | |||
| Defroster | yes | ||||
| Instrument | Bus instrument, English system | ||||
| Audio-system | MP5 TV | ||||
| Lights | Front and rear combination light. Fog light. | ||||
| Monitoring system | CCTV system with 5 cameras | ||||
| Bus facilities | Body | Semi-loaded | |||
| Passenger door | Front aluminum swing door | ||||
| Window | Sliding side window, laminated front windscreen and tempered rear-shield | ||||
| Passenger seat | 45 artificial leather passenger seats | ||||
| Interior | PVC duct, PVC composite side plate. | ||||
| Floor and floor cover | PVC floor, anti-slippery, flame retardant leather | ||||
| Paint | Solid paint | ||||
| Others | Safety hammer with alarm function,Electronic clock,Manual fire distinguisher ,Auto fire distinguisher in engine cabin,USB connector at driver area,travel record with GPS | ||||
Q: Who we are?
A: ZEV is a group company specializing in buses and coaches R&D, manufacturing and marketing. From its foundation in 2000’s, ZEV’s culture of continuous innovation has made it a leading manufacture in China. Now we have developed a series of Electric BUS&COACH as well as Hydrogen fuel cell bus. There will always be a model that suits you the most.
Q: What can we offer?
A:
Q: Do you accept customized service?
A: Yes. We can offer customized service according to your requirements .
Q: What’s the delivery time?
A: Normally 20-35 workdays.
Q: Why choose us?
A: We guarantee professional service, competitive price with high quality vehicles.
